Pro Convert SDI Plus

£0.00

Converts one-channel of 3G-SDI input signal into Full NDI® with loop-through

Part number:
64040 US; 64042 EU; 64043 UK;
64044 AU; 64045 KR; 64046 JP

The device is supplied with different options of power adapters.

  • Supports up to 2048×1080 60fps input signals
  • Connects existing source equipment into NDI-enabled, IP-based media networks
  • Plug-and-play ease of use with automatic input format detection and DHCP network configuration
  • Supports 16 audio channels

Interface

SPECIFICATION & FEATURES

Input Features

  • 3G-SDI input and loop-through
  • Support for up to 2048×1080 60fps input
  • Support for up to 16 (mono) audio channels

NDI® Format

  • Support for up to 2048×1080 60fps 4:2:2 8-bit NDI encoding
  • Send NDI streams across network segments
  • Remotely control PTZ cameras via NDI
  • Support for NDI 5.x

Features & Advantages

  • Very low latency
  • Advanced configuration and device status through intuitive Web GUI
  • Tally lights and camera mounting for live production applications
  • HTTP-based APIs for custom integration

FULL SPECIFICATION & FEATURES

  • Input & Loop through Features

    • Max video input & loop through: 2048×1080 60fps. Supported resolutions include:
      • 2048x1080p/1920x1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60
      • 2048x1080i/1920x1080i 23.98/24/25/29.97/30/47.95/48/50/59.94/60
      • 1280x720p 50/59.94/60
      • 720×576 25p/50i (PAL SD)
      • 720×480 29.97p/59.94i (NTSC SD)
    • Support RGB/RGBA/YUV/YUVA signals with 10/12-bit color depth
    • Support RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
    • Support RGB, YUV BT.601/709/2020 video input
    • 16-channel SDI embedded audio inputs
    • SD/HD/3G-SDI BNC input & loop through
    • Support SD (ST 259)/HD (ST 292)/3Ga (ST 425)/3Gb (ST 425)/3Gb-DL (ST 425)/3Gb-DS (ST 425) SDI standards
    • Receive 3G-SDI transmitted up to 200m (656ft)

    NDI® Encoding Features

    • Encoding Full NDI real-time stream at up to 2048×1080 60fps 4:2:2 8-bit
    • Output the same resolution as input or any custom resolution. Typical outputs include:
      • 2048x1080p/1920x1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60
      • 2048x1080i/1920x1080i 25/29.97/30/47.95/48/50/59.94/60
      • 1280x720p 50/59.94/60
    • Output frame rate same as the original, 1/2, 1/3 or 1/4 of input frame rate
    • Encoding 16-channel NDI-embedded audio
    • Support NDI 5.x

    Configuration Management

    • Register with Magewell Cloud
    • Remote control via WebUI and Magewell Cloud
    • Provide comprehensive information regarding the device and signals in real-time
    • Allow to configure how an input is processed and encoded, including deinterlacing, up/down scaling, frame rate, aspect ratio, as well as the network connection
    • Update firmware
    • Support USB RNDIS/ECM
    • Support IE/Edge/Firefox/Chrome/Safari/Opera web browsers
    • Provide HTTP APIs

    On-board Control Buttons

    • 16 Position Rotary DIP Switch: set board-index from 0 to F

    PTZ Control

    • Control PTZ cameras using protocols of VISCA, Visca UDP, Visca UDP2rs232, PELCO-P and PELCO-D via NDI
    • Mini-DIN–8 jack (shared with Tally light)

    Network Interfaces

    • 10/100/1000Mbps Ethernet
    • IEEE 802.3af PoE

    USB Interface

    • USB2.0 Type B
      • 5V/2.1A power supply
      • USB RNDIS/ECM

    Supported Products

    • NDI Studio Monitor
    • OBS
    • vMix
    • Any other NDI-enabled product

    LED Indicators

    • Status LEDs indicate:
      • Power supply: on/off
      • Tally: preview/program
      • Input signal: locked/unlocked
      • Loop through signal: on/off

    Form Factor

    • 117.5mm (L) x 66.7mm (W) x 23.4mm (H)

    Accessories

    • USB 2.0 A to B cable
    • 5V/2.1A power adaptor
    • Mini-DIN 8 breakout cable
    • Tally light
    • L-bracket

    Screw Mounting Hole

    • ¼–20 threaded hole

    Power Consumption

    • 5V max current: ~1.5A
    • Max power consumption: ~7W

    Working Environment

    • Operating temperature: 0 to 45 deg C
    • Storage temperature: –20 to 70 deg C
    • Relative humidity: 5% to 90% non-condensing

Firmware

Firmware
Descriptions:
  1. Support toggling on/off SSDP. When toggled off, it does not send SSDP multicast packet.
  2. Support Auto Reboot to set periodical auto reboot.
  3. Support adding multiple discovery servers.
  4. “set-rndis-config” API adds the “name” parameter, which is used to modify the name of USB device.
  5. Fix known issues.
